The startup dialog box can be activated through the use of the STARTUP system variable. Describe the procedure to activate the AutoCAD Startup option. Center, Start, End arc: Draws an arc using three specified points the first point is the Center point, the second point is the start point and the third point is the endpoint.ģ Ch. The second point is a point on the circumference of the arc. 3 points arc: Draws an arc using three specified points on the arc's circumference. To create an arc, we can specify combinations of center, endpoint, start point, radius, angle, chord length, and direction values. List and describe two methods to create arcs in AutoCAD.
#Template file for mastercam 2019 how to#
Find information on how to draw arcs in AutoCAD through the InfoCenter and create the following arc. If it is desired to position the center of the ellipse to a specific location, which ellipse commands is more suitable? The Center Ellipse command can be used to position the center of the ellipse to a specific location. Find information on how to draw ellipses in AutoCAD through the InfoCenter and create the following arc. But it does not change the coordinates of objects. This function acts as if you are using a video camera. When you use the Pan command, does the coordinates of objects get changed? The Pan command enables us to move the screen view to a different position. Which key do you use to quickly cancel a command? The key can be used to quickly cancel a command. The two types of coordinate systems commonly used for planar geometry are the Cartesian coordinate system and the Polar coordinate system. List and describe the two types of coordinate systems commonly used for planar geometry.
When using the Line command, which option allows us to quickly create a linesegment connecting back to the starting point? The Close option allows us to quickly create a line-segment connecting back to the starting point.Ģ 6. Direct Distance entry technique: Specify a second point by first moving the cursor to indicate direction and then entering a distance. Relative polar coordinates Type a distance and angle relative to the last point. Relative rectangular coordinates Type the X and Y coordinates relative to the last point. Absolute coordinates (Format: X,Y): Type the X and Y coordinates to locate the point on the current coordinate system relative to the origin. Interactive method: Use the cursor to select on the screen. List and describe the different coordinate entry methods available in AutoCAD? In AutoCAD, there are five methods for specifying the locations of points when we create planar geometric entities. How do the GRID and SNAP options assist us in sketching? The GRID and SNAP options can be used to provide a visual reference as to the size of objects and to restrict the movement of the cursor to a set increment on the screen. The DWG file format can contain 2D or 3D objects and offers compression and a CRC check for internal data error.
The DWG file format is a binary file format created and used by AutoCAD. What is the default AutoCAD filename extension? The default AutoCAD filename extension is DWG. Electronic format of CAD drawings are fragile as CAD files can be lost accidentally after a power failure, a hardware crash or even human mistakes.
Trainings are required to implement using the CAD systems, which may require additional time and money.
#Template file for mastercam 2019 software#
Disadvantages of using CAD systems to create engineering drawings: Initial cost to purchase CAD hardware and software can be quite high. A lot of the information stored in the CAD database can be re-used during the manufacturing processes.
#Template file for mastercam 2019 portable#
Large number of CAD drawings can be easily moved, from one location to another, by using portable storage devices. CAD drawings can be easily transferred through internet. Engineering Drawings created by CAD systems can be re-used and modified faster. What are the advantages and disadvantages of using CAD systems to create engineering drawings? Advantages of using CAD systems to create engineering drawings: Faster and more accurate geometric constructions.
